LRS-200-12 30mm ultra thin slim typy ac to dc 85-264VAC 200w 12v switching power supply

FOB Reference Price:Get Latest Price
US $13-14 / Piece | 1 Piece/Pieces 12v switching power supply (Min. Order)
Supply Ability:
80000 Piece/Pieces per Month factory direct sale
Port:
shanghai ningbo
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
WEHO
Model Number:
LRS-200-12
Output Power:
200w
Output Type:
Single
Input Voltage:
110v or 220v
Output Voltage:
12v
Output Frequency:
47hz-63hz
Output Current:
17a
OEM:
yes
Shell material:
Aluminium
Overall dimension:
215*115*30mm
weight:
0.66Kgs
Start, Rise, Hold time:
1300ms,50ms/230VAC 1300ms,50ms/115VAC at full lod
Workig temperature:
-10℃~+50℃
Efficiency:
88%
Label:
we can stick customer's label
Payment term:
30% deposit
Output protections:
OLP/OVP/SCP
Packaging & Delivery
Packaging Details
15pcs /carton
Delivery Time
3-5days
Related Products

ModelLRS-200-5LRS-200-12LRS-200-15LRS-200-24LRS-200-36LRS-200-48
Dc output voltage5V12V15V24V36V48V
Rated output current40A17A14A8.8A5.9A4.4A
Output current rage0-40A0-17A0-14A0-8.8A0-5.9A0-4.4A
Rated  Power200W204W210W211.2W212.4W211.2W
Wave and noise150mVp-p150mVp-p150mVp-p150mVp-p200mVp-p200mVp-p
Voltage ADJ. range4.5-5.5V10.2-13.8V13.5-18V21.6-28.8V32.4-39.6V43.2-52.8V
Voltage tolerance±3%±1.5%±1%±1%±1%±1%
Line Regulation±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
Load Regulation±2%±1%±0.5%±0.5%±0.5%±0.5%
Efficiency86.0%88.0%88.5%90.0%90.5%91.0%
AC input voltage rangeAC85~132AC/170~264V By switch  47~63Hz; 240~370VDC (Switch on 230VAC)
Input current4A/115V   2.2A/230V
AC INnrush currentCold-start  60A/115V,60A/230V
Overload proctection110%~140% Potection type: Hiccp mode,recobers automatically after condition recoverd
Over-voltage protection5.75-6.75V13.8-16.2V18.75-21.75V28.8-33.6V41.4-48.6V55.2-64.8V
Potection type :Shut down o/p voltage,re-power on to recover
Setup rise time1300ms,50ms/230VAC 1300ms,50ms/115VAC at full lod
 Hold up time16ms/230VAC ,12ms/115VAC at full lod
Withstand voltage I/P-O/P:3.75KVAC,I/P-FG:2KVAC,O/P-FG: 1.25KVAC
Isolation resistance I/P-O/P,I/P-FG,O/P-FG:100M Ohms/ 500VDC /25°C/70%RH
Working temperature-30°C~+70°C
Overall dimension215*115*30mm
Safety standardsMeet ULGB4943 UL60950 EN60950
EMC standardsMeet EN55022,EN61000-3-2,EN61000-3-3,EN55024 GB9254 Class B
Weight0.66Kgs
